Divisor De Tres Vías 555-2700 MHz
Modelo del producto: S-3-CPUSE-H-NI6
Tipo de produto: Filtros y Sistemas para RF
por ANDREW
Agotado
$ 0.00
| Electrical Specifications | |
| Operating Frequency Band | 555 – 2700 MHz |
| 3rd Order IMD | -160.0 dBc |
| 3rd Order IMD Test Method | Two +43 dBm carriers |
| Average Power, maximum | 300 W |
| Impedance | 50 ohm |
| Insertion Loss at Frequency Band | 0.2 dB @ 555–2700 MHz |
| Peak Power, maximum | 3 kW |
| Power Rating, Splitting | 300 W |
| Reflected Power, maximum | 300 W |
| Return Loss, minimum | 20.8 dB |
| Split Loss | 4.8 dB |
| VSWR | 1.20 |
