Acoplador Direccional De 10 dB 555-2700 MHz

Modelo del producto: C-10-CPUSE-N-AI6

Tipo de produto: Filtros y Sistemas para RF

por ANDREW
Agotado
$ 0.00
Electrical Specifications
Operating Frequency Band   555 – 2700 MHz
3rd Order IMD   -160.0 dBc
3rd Order IMD Test Method   Two +43 dBm carriers
Average Power, maximum   200 W
Coupling   10.0 dB
Coupling Tolerance   ±1.0dB @ 698–2700 MHz   |   ±2.0dB @ 555–698 MHz
Impedance   50 ohm
Insertion Loss at Frequency Band   0.7 dB @ 575–2700 MHz
Isolation at Frequency Band   30 dB @ 555–2700 MHz
Peak Power, maximum   1 kW
Reflected Power, maximum   100 W
Return Loss, minimum   20.8 dB
VSWR   1.20
